Get ready to conquer the road less traveled. The 4130 All-Road frameset is now more versatile than ever, featuring key upgrades to enhance your riding experience. With Universal Derailleur Hanger (UDH) compatibility, dropper post readiness, and semi-internal cable routing, it’s built for adaptability. Whether you're hitting the gravel, tackling a bikepacking adventure, or commuting in style, this frame has you covered.

What's New?

• Wider Tire Clearance: Fit up to 2.4” tires with 650b wheels for even more off-road capability.
• Added Mounting Points: Bring along everything you need, from bikepacking gear to commuter essentials.

Specifications:

• Frame: 4130 Chromoly Steel with Thru-Axle Dropouts (142mm spacing)
• Fork: 4130 Chromoly Steel with Thru-Axle Dropouts (100mm spacing)
• Max Tire Clearance:
  • 650b Wheels: Up to 2.4"
  • 700c Wheels:
    • Standard Fork: 45mm
    • Monster Fork: 2.1" (55mm)
• Sizes:
  • XS: 5'1"–5'6"
  • S: 5'5"–5'10"
  • M: 5'9"–6'2"
  • L: 6'1"–6'5"
• Weight:
  • Frame (size M): 2780g

  • Fork (uncut): 1300g

Also Included:

• FSA ZS-4D 1 1/8" Threadless Headset
• Stealth Thru-Axles  Front & Rear(M12 Thread Pitch, 100mm front / 142mm rear)
• Universal Derailleur Hanger
• Cable Guides

Risk-Free Purchase:
Not sure if it’s the right fit? We’ve got you covered with FREE EXCHANGES! If it doesn’t work out, we’ll send you a return label and swap it for free.*

Ready to dive into the details? Full Geo/Specs here.
